A decade ago, Kinco pioneered frameless torque motor technology for robotics. Today, the FMK series represents our fourth-generation innovation, featuring an optimized stator welding process, improved stator roundness, and a minimized axial length—all while delivering superior performance to meet diverse customer requirements.
Features
- High torque density – Optimized motor electromagnetic design, lightweight harmonic gearing and structural components, and a reduced drive footprint maximize the joint module’s torque density.
- High rotational speed – Supports speeds up to 50 rpm
- Modular and highly integrated design – Fewer parts, lower overall weight, and improved reliability.
- Precise thermal management – Equipped with low-latency, high-accuracy temperature sensors for real-time motor temperature monitoring and over-temperature protection.
- Available outer diameters – 55 mm, 60 mm, 70 mm, and 80 mm (custom options available).
iFMH rotary joint modules are widely used in
Industrial Production, Security Patrol, Delivery Service, Guided Tours
Specifications
| Specifications | iFMH55H | iFMH60H | iFMH70H | iFMH80H |
| Rated Voltage (VDC) | 48 | 48 | 48 | 48 |
| Gear Ratio | 100 : 1 | 100 : 1 | 100 : 1 | 101 : 1 |
| Peak Start-Stop Torque (N·m) | 19 | 37 | 57 | 51 |
| Rated Torque (N·m) | 7.7 | 27 | 34 | 51 |
| Maximum Momentary Torque (N·m) | 35 | 71 | 95 | 143 |
| Rated Speed (rpm) | 37 | 35 | 31 | 35 |
| Maximum No-Load Speed (rpm) | 50 | 48 | 38 | 45 |
| Rated Power (W) | 29.8 | 99 | 110.4 | 186.9 |
| Peak Torque Density (Nm/Kg) | 79 | 109 | 117 | 127 |
| Input Voltage Range (VDC) | 20~72 | 20~72 | 20~72 | 20~72 |
| Encoder Type | Absolute Encoder | Absolute Encoder | Absolute Encoder | Absolute Encoder |
| Encoder Resolution | 19-bit | 19-bit | 19-bit | 19-bit |
| Dimensions (mm) | Φ55*70 | Φ62*76 | Φ70*76 | Φ80*84 |
| Hollow Bore Diameter (mm) | Φ8.4 | Φ8.5 | Φ12 | Φ16 |
| Weight (g) | 445 | 650 | 815 | 1130 |
Files to download
Here you will find a comprehensive set of technical resources for our robotic motors, servo modules, and wheeled servos—including datasheets, user manuals, debugging software, brochures, selection guides, as well as CAD files and 2D models.
